Tianjin Kangli Medical Equipment Co., Ltd. helps international healthcare brands, wholesalers, and manufacturers develop medical equipment through OEM collaboration. When buyers ask, "what is the slope of a wheelchair ramp," the standard U.S. ADA answer is a maximum running slope of 1:12 for ordinary accessible ramp runs. That means one unit of vertical rise for every twelve units of horizontal distance—approximately 8.33%, or 4.76 degrees.
Founded in 1998, Kangli operates a 20,000-square-meter factory with more than 50 employees. Our medical equipment perspective encourages buyers to consider the complete care environment, not just an individual product.
For wheelchair access, slope is only the starting point. Width, landings, drainage, door clearance, and the user's mobility equipment all influence whether an access route works in practice.
This guide explains the numbers, shows how to calculate ramp length, and provides a practical checklist for families, healthcare facilities, and B2B buyers.
Under Section 405.2 of the U.S. ADA Accessibility Standards, ordinary ramp runs on accessible routes must not be steeper than 1:12.
For every inch of rise, provide at least twelve inches of horizontal run. A six-inch height difference therefore requires at least six feet of horizontal ramp run at this maximum slope.
The important distinction is that 1:12 is a maximum permitted steepness, not a universal comfort target.
The U.S. Access Board advises using the least possible slope to accommodate a wider range of people. A gentler route may improve usability, although additional length also creates more travel distance.
Before finalizing a design, confirm which rules apply to the property. ADA requirements, local building codes, residential provisions, and regulations outside the United States are not interchangeable.
Running slope follows the direction of travel. It describes the uphill or downhill incline.
Cross slope runs across the width of the ramp. Excessive sideways tilt can make straight travel more difficult.
For ordinary ADA ramp runs:
- Maximum running slope: 1:12, approximately 8.33%.
- Maximum cross slope: 1:48, approximately 2.08%.
A ramp can meet the running-slope limit and still fail because its surface tilts too much sideways.
For example, a ramp rising six inches over seventy-two horizontal inches has a slope of:
This equals a 1:12 ratio.
For a preliminary layout:
| Vertical rise | Horizontal run at 1:12 |
|---|---|
| 2 inches | 24 inches / 2 feet |
| 4 inches | 48 inches / 4 feet |
| 6 inches | 72 inches / 6 feet |
| 12 inches | 144 inches / 12 feet |
| 24 inches | 288 inches / 24 feet |
| 30 inches | 360 inches / 30 feet |
These figures cover the sloped run only. They do not include top, bottom, or intermediate landings.
Metric calculations work identically. A 300 mm rise requires 3,600 mm of horizontal run at 1:12, before adding landing space.
A frequently overlooked detail is that slope calculations use horizontal distance, not the diagonal length of the ramp deck.
The actual deck is slightly longer than its horizontal projection.
When reviewing portable-ramp specifications, ask whether the listed length describes the deck or its horizontal reach. Using the wrong dimension can produce an inaccurate slope calculation.
A larger second number means a gentler incline.
| Ratio | Percentage | Practical interpretation |
|---|---|---|
| 1:8 | 12.5% | Too steep for ordinary ADA ramp runs |
| 1:10 | 10% | Too steep for ordinary ADA ramp runs |
| 1:12 | 8.33% | Standard ADA maximum running slope |
| 1:16 | 6.25% | Gentler incline requiring more space |
| 1:20 | 5% | ADA walking-surface running-slope boundary |
The 1:20 boundary has a specific regulatory meaning. Under ADA standards, accessible walking surfaces may have running slopes no steeper than 1:20; steeper accessible-route surfaces must be treated as ramps.
However, a gentle slope does not remove other obligations. Surface condition, clear width, cross slope, and applicable handrail requirements still need review.
Not necessarily.
Compliance establishes dimensional requirements. It does not prove that every person can independently use every compliant route.
The Access Board notes that long ramp systems can be strenuous for manual wheelchair users. Intermediate landings provide resting opportunities, but they do not eliminate the effort required to gain elevation.
Planning should therefore consider:
- Whether the user self-propels or uses powered mobility.
- How frequently the route will be used.
- Total elevation change and travel distance.
- Whether assistance is normally available.
- Exposure to rain, snow, or surface contamination.
- Space for approaching, stopping, and turning.
For a specific person, involve an accessibility professional and, where appropriate, an occupational therapist. Confirm the wheelchair manufacturer's operating limits rather than treating the building-code slope as a device capability rating.
Ordinary ADA ramp runs require at least 36 inches of clear width.
Where handrails are installed, measure between them—not between the outer edges of the structure.
Healthcare facilities may need additional width for their intended traffic or applicable exit requirements. A minimum accessibility dimension should not automatically become the operational design target.
Provide landings at the top and bottom of each ramp run.
Under the ordinary ADA ramp provisions:
- Landing length must be at least 60 inches.
- Landing width must match or exceed the widest connecting ramp run.
- A change in direction between runs requires at least 60 by 60 inches of clear landing space.
- Landing slopes must not exceed 1:48.
Do not assume that a landing alone supplies all required doorway clearance. Door approach, swing, latch position, and maneuvering space must also be checked.
Each ordinary ADA ramp run is limited to 30 inches of rise.
The often-repeated instruction to "add a landing every thirty feet" is incomplete. Thirty feet corresponds to thirty inches of rise at 1:12.
At a gentler slope, the same permitted rise requires a longer run. The governing limit is rise, not a universal thirty-foot distance.
Ordinary ramp runs rising more than six inches require handrails on both sides, subject to specific exceptions.
Edge protection is generally required along runs and landings, with defined exceptions.
Also check that surfaces are firm, stable, and slip resistant. Outdoor landings must be designed to prevent water accumulation.
Slope compliance cannot compensate for missing edge protection, obstructed landings, or a poorly maintained surface.
A useful inspection records both overall geometry and local variations.
1. Measure the vertical difference between the lower and upper levels.
2. Measure the horizontal projection of each run.
3. Calculate the running slope.
4. Check local slope along the run with suitable measuring equipment.
5. Measure cross slope separately.
6. Record clear width, landing dimensions, and doorway clearance.
7. Inspect transitions, drainage, handrails, and exposed edges.
An average measurement can conceal a steeper section or abrupt transition.
For compliance decisions, use a qualified surveyor, architect, engineer, or accessibility specialist as appropriate. A phone inclinometer may support an initial observation, but it should not substitute for a professional inspection.
Consider a hypothetical clinic entrance twelve inches above the approach surface.
At 1:12, the preliminary horizontal run is twelve feet.
At 1:16, it becomes sixteen feet.
At 1:20, it becomes twenty feet.
The gentler options require more space, so compare the whole layout rather than slope alone. Add landings, doorway maneuvering clearances, and a suitable connection to the existing path.
If a straight arrangement does not fit, investigate a professionally designed turning layout. A direction change requires a suitable landing; a continuously curved incline is not a simple substitute.
Where elevation or space makes a ramp impractical, ask a qualified designer whether another permitted access solution is appropriate.
This is a planning illustration, not a documented Kangli installation or a construction drawing.
A drawing marked 1:12 leaves little allowance for installation variation.
The Access Board's technical guide recommends a maximum design running slope of 7.5% and cross slope of 1.5% for exterior ramps to accommodate common construction irregularities.
These are design recommendations, not replacements for the regulatory limits.
For buyers, this creates an important procurement distinction:
- Design slope describes the intended geometry.
- As-built slope describes the installed result.
- Acceptance criteria define what must be verified before handover.
Ask contractors how they will control slope, check finished surfaces, and correct nonconforming areas. Avoid accepting a drawing as proof that the completed installation complies.
For brands and distributors, "ADA-compliant slope" is not a complete product specification.
Request information covering:
- Intended use and destination-market requirements.
- Installed rise and usable horizontal reach.
- Clear width after rails or barriers are fitted.
- Rated capacity and supporting test documentation.
- Required anchoring, bearing surfaces, and installation conditions.
- Surface treatment and drainage.
- Inspection, cleaning, and maintenance instructions.
- Compatibility with the intended mobility devices.
Portable products need particular care. A portable ramp does not automatically replace a permanent accessible route. The Access Board explains that required ramps generally must be permanent, with limited exceptions.
Similarly, a powered wheelchair's stated climbing capability does not establish building accessibility compliance.
Tianjin Kangli Medical Equipment Co., Ltd. serves overseas brands, wholesalers, and manufacturers seeking medical equipment OEM cooperation.
Our perspective is straightforward: evaluate equipment within the care setting where it will actually be used. Access routes, room layouts, and transfer spaces belong in that conversation.
For an OEM inquiry, send your target market, product category, expected order volume, drawings, branding requirements, and documentation needs. For ramp-specific products, ask our team to confirm capability and scope before assuming availability.
Website: www.klmedbed.com
Email: yukili90@tjkangli.com
Phone / WhatsApp: +86 136 5207 7555
This guide supports preliminary planning. It does not certify a product or installation, replace local approval, or provide individualized mobility advice.
For ordinary accessible ramp runs, the maximum running slope is 1:12, approximately 8.33% or 4.76 degrees. Specific existing-site exceptions have tightly limited conditions.
At 1:12, provide at least six feet of horizontal run. Add the required landings and check doorway maneuvering space separately.
Not for ordinary new accessible ramp runs. In existing sites with space limitations, narrowly defined exceptions permit certain steeper slopes over limited rises. Do not apply those exceptions as general design permission.
Under ordinary ADA ramp provisions, runs rising more than six inches require handrails on both sides, subject to specified exceptions. Other applicable codes may also affect the installation.
No. Five percent equals a 1:20 ratio and approximately 2.86 degrees. Percent grade and degrees measure incline differently and must not be substituted for each other.
Not automatically. Required ramps generally must be permanent, with limited exceptions. Compliance also depends on the complete route, including landings, width, surface, and doorway clearances.
No. ADA is a U.S. framework. Overseas projects must follow the destination country's applicable accessibility regulations, construction requirements, and product obligations.
